Ozone Aging Test Chamber

Ozone Aging Test Chamber

Product Details:

  • Product Type Ozone Aging Test Chamber
  • Voltage 220-440 Volt (v)
  • Application Industrial
  • Power Supply Electric
  • Material Metal
  • Click to View more

Ozone Aging Test Chamber Price And Quantity

  • 1 Unit

Ozone Aging Test Chamber Product Specifications

  • Industrial
  • 220-440 Volt (v)
  • Metal
  • Electric
  • Ozone Aging Test Chamber

Ozone Aging Test Chamber Trade Information

  • Cash Advance (CA)
  • 30 Days
  • Central America North America South America Western Europe Middle East Eastern Europe Asia Australia Africa
  • All India

Product Description

Ozone Aging Test Chamber is precision designed as per rubber being sensitive feature of to the ozone. This kind of test chamber can simulate the climatic to accelerate the rubber aging procedure by ozone. Completely powder coated stainless steel body is mounted on four castors for moving the chamber easily across the testing section. It is equipped with imported micro-computer LCD controller for safely and easily controlling the temperature. With automatic calculation function, it can reduce the setting inconvenience. To ensure ozone resistance, all the internal parts of Ozone Aging Test Chamber is made of high-grade mirror finishing stainless steel.




Internal dimension (WxDxH)


External dimension (WxDxH)


Temperature range

RT+10 to 60degree C (suggest to use 40degree C-/+2degree C)

Temperature Fluctuation

-/+1degree C

Ozone concentration

50 to 1000 pphm, adjustable

Ozone concentration deviation


Sample holder

SUS#304 stainless steel

Temperature controller

Programmable touch screen controller

Ozone concentration analysis

Concentration analysis meter

Ozone generator

High pressure silence discharge type

Protection system

Leakage, short circuit, over temperature, over heat

Test criteria

ASTM D1149, ISO 1431, JIS K6259...


Frequently Asked Questions

Q. What's an ozone aging check chamber?

A. An ozone aging test chamber is a testing out gadget that simulates ozone exposure conditions to evaluate the getting older and degradation of numerous materials together with rubber, plastic, and textiles.

Q. How does an ozone-growing older check chamber work?

A. An ozone aging test chamber generates ozone fuel by using electrical discharge and introduces it into the test chamber in which the check samples are positioned. The samples are exposed to the ozone gas at targeted attention and period consistent with the specific test requirements or test situations.

Q. What are the standard take a look at requirements for ozone aging take a look at chambers?

A. The most common test standards for ozone growing older test chambers include ASTM D1149, ISO 1431, GB/T 7762, and JIS K6259.

Q. What types of merchandise can be tested with the use of an ozone-growing older test chamber?

A. An ozone aging check chamber may be used to test a huge range of products along with rubber seals, gaskets, hoses, belts, o-rings, insulators, coatings, adhesives, and more.
