Electrodynamic Vibration Test System

Electrodynamic Vibration Test System

Product Details:

  • Usage Industrial
  • Product Type Vibration Test System
  • Material Metal
  • Power Supply Electric
  • Click to View more

Electrodynamic Vibration Test System Price And Quantity

  • 1 Unit

Electrodynamic Vibration Test System Product Specifications

  • Vibration Test System
  • Industrial
  • Metal
  • Electric

Electrodynamic Vibration Test System Trade Information

  • Cash Advance (CA)
  • 30 Days
  • Asia Central America South America Western Europe Middle East Eastern Europe North America Australia Africa
  • All India

Product Description

Electrodynamic Vibration Test System that our well-established and reliable enterprise puts forward is ideal for mechanical shock, transportation simulation, Environmental Stress Screening, and mission profile tests. This kind of test system has capability of simulating a large array of situations that helps in improving product, test quality as well as reliability, by enhanced and dynamic performance in acceleration, force, displacement, and velocity. Electrodynamic Vibration Testing Machine is well featured with air spring load support, fully sealed & double magnetic circuit structure, strong ear-shaft design along with bearing guide, built-in rubber vibration isolation device or airbag for reducing ground dynamic vibration.




Electrodynamic vibration generator system

Rated Force (peak) under sinusoidal


Impact thrust


Frequency range

200 Hz

Continuous displacement

59 mm p-p

Impact displacement

59 mm p-p

Maximum rated speed (sin peak)


Maximum Acceleration (sin)

0.53 m/s2

Diameter of moving coil

445 mm

Allowable unbiased load torque

300 N.m

Equivalent mass of moving parts

301 g

Axial vibration isolation frequency

2.5 Hz

Maximum load for sample

500 kg

Magnetic flux leakage

10 gauss

Vertical vibration tester size

4505x2500x840 mm(LxWxH, without package)

Vertical vibration tester weight

About5800 kg (without package)

Power amplifier

Maximum output power

32 kVA

S/N (Signal-to-noise Ratio) S-/N

65 dB

Rated output voltage

100 V

Conversion efficiency


System protection

Output over-voltage, output over flow, amplifier over temperature, vibration table over displacement, horizontal slide over the displacement, cooling system failure, output power under-voltage, amplifier unit failure, excitation power failure, three-phase power supply failure, etc.

Power amplifier size

1720x1200x850 mm (LxWxH, without package)

Vertical spreading table

Table size

1100 x1100mm


Aluminum alloy

Upper operating frequency

500Hz (Sine)


Fan power

15 kW

Blowing rate

22 m3/min

Vibration controller

Host hardware

2 analog voltage/IEPE/electric charge/TEDS(can be optional) input channel, built-in 24-bit ADC and IEPE constant current source and charge amplifier per channel, 32-bit floating-point DSP processor, 1 analog voltage output channel, 24 DAC resolution  rugged chassis design with emergency stop button and earthing terminal

Control software

Random control: Test bandwidth 1-5000hz, support multi-channel control strategy, random channel limit (notching) control, etc.

Sine control: Test bandwidth 1-5000hz, including constant frequency, stepping, sweep sine, support multi-channel control strategy, sinusoidal channel limit (notching) control, harmonic distortion measurement.

Typical impact: support electromagnetic requirements according to international standards.

Resonance search and reside

Acceleration sensor

The host hardware

Sensitivity 30pc/g, frequency response 0.5-7000hz, mileage 500g, weight 10g, side-end outlet, 6-meter-long dedicated low noise cable temperature range -40 degree to 160deree





I3-4170-3.7GHz/DDR3-4GB/500GB/17 inches

Spare parts

 fuse links and fuse cutout, etc.



1. What is a system for testing electrodynamic vibration?

Ans - To assure a product's performance and dependability, a technology called an electrodynamic vibration test system is utilised to replicate a variety of vibration scenarios. It is frequently used to evaluate the effectiveness of mechanical, electrical, and other components.

2. What advantages can electrodynamic vibration test systems offer?

Ans - Manufacturers can assess a product's performance and reliability using an electrodynamic vibration test system. Additionally, it may be utilised to simulate a variety of vibrational settings, enabling more precise testing outcomes.

3. What kinds of parts can an electrodynamic vibration test system test?

Ans -Many different types of components, including electrical components, mechanical components, and other products, can be tested using an electrodynamic vibration test system.

4. How do systems for measuring electrodynamic vibrations operate?

Ans - The method by which Electrodynamic Vibration Test Systems generate a variety of various vibrational frequencies and amplitudes is the use of a shaker or other vibration instrument. The product being tested is then subjected to these vibrations in an effort to imitate the various vibration situations it would experience in usage.

5. Is operating an electrodynamic vibration test system challenging?

Ans - No, using an electrodynamic vibration test system is typically simple. The systems often have simple controls and user-friendly interfaces, making setup and use simple.
